Centon, 100-ball BGA (Industrial), MLC, 16GB

Product Details

eMMC (embedded Multimedia Card) combines NAND flash and a controller in a single soldered-down BGA package, delivering compact, low-power, non-removable storage for cost-sensitive embedded designs.

Item No.	E5-100IM-16G
Interface	eMMC 5.1 HS400
Form Factor	100-ball BGA
Operating Temperature	Industrial: -40 to +85C
Size	16GB
Sequential Write (MB/s)	125
Sequential Read (MB/s)	320
Voltage	3.3V
I/O Voltage (VCCQ)	3.3V/1.8V
W/E Endurance	≥ 3K
Package Size	14.0 x 18 x 1.4 mm
Data Retention	1-Year @ life-end \| 10-Years @ initial

Similar parts

View all →

Part number	Package	Temperature	Capacity	NAND
E5-100IP-4G	100-ball BGA	Industrial -40°C to 85°C	4GB	pSLC
E5-100IM-8G	100-ball BGA	Industrial -40°C to 85°C	8GB	MLC
E5-153IP-4G	153-ball BGA	Industrial -40°C to 85°C	4GB	pSLC
E5-153IM-8G	153-ball BGA	Industrial -40°C to 85°C	8GB	MLC
E5-153IM-16G	153-ball BGA	Industrial -40°C to 85°C	16GB	3D TLC (64-Layer)
E5-153IT1-32G	153-ball BGA	Industrial -40°C to 85°C	32GB	3D TLC (64-Layer)
E5-153IT2-64G	153-ball BGA	Industrial -40°C to 85°C	64GB	3D TLC (112-Layer)
E5-153IT2-128G	153-ball BGA	Industrial -40°C to 85°C	128GB	3D TLC (112-Layer)
E5-153IT2-256G	153-ball BGA	Industrial -40°C to 85°C	256GB	3D TLC (112-Layer)
E5-153IT1-64G	153-ball BGA	Industrial -40°C to 85°C	64GB	3D TLC (128-Layer)
E5-153IT1-128G	153-ball BGA	Industrial -40°C to 85°C	128GB	3D TLC (128-Layer)
