Centon, 153-ball BGA (Industrial), pSLC, 4GB

Product Details
eMMC 5.1 puts NAND flash and its controller in one soldered BGA package, with ECC, wear leveling and bad-block management built in, so your design boots and runs from a single chip that cannot shake loose. Choose the temperature grade and NAND type (pSLC, MLC or 3D TLC) that fit your endurance and cost targets. Centon builds it to a controlled bill of materials with full lot traceability and keeps it in supply for long-running embedded programs.

Item No. E5-153IP-4G
Interface eMMC 5.1 HS400
Form Factor 153-ball BGA
Operating Temperature Industrial: -40 to +85C
Size 4GB
Sequential Write (MB/s) 100
Sequential Read (MB/s) 260
Voltage 3.3V
I/O Voltage (VCCQ) 3.3V/1.8V
W/E Endurance ≥ 30K
Package Size 11.5 × 13.0 × 1.0 mm
Data Retention 1-Year @ life-end | 10-Years @ initial
Lifecycle StatusProduction
RoHSCompliant
REACHCompliant
MOQLow MOQ
Lead TimeQuoted per order
Optima: BOM control

Critical parts fixed. NAND may move to qualified equivalents under the same part number.

Optima+: 100% BOM control

Every part locked. Any change gets a new part number.

Same specifications. Our sales team will help you choose.

Similar parts

View all →
Part numberCapacityNANDPackageTemperature
E5-100IP-4G4GBpSLC100-ball BGAIndustrial -40°C to 85°C
E5-100IM-8G8GBMLC100-ball BGAIndustrial -40°C to 85°C
E5-100IM-16G16GBMLC100-ball BGAIndustrial -40°C to 85°C
E5-153IP-4GThis part4GBpSLC153-ball BGAIndustrial -40°C to 85°C
E5-153IM-8G8GBMLC153-ball BGAIndustrial -40°C to 85°C
E5-153IM-16G16GB3D TLC (64-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT1-32G32GB3D TLC (64-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT2-64G64GB3D TLC (112-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT2-128G128GB3D TLC (112-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT2-256G256GB3D TLC (112-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT1-64G64GB3D TLC (128-Layer)153-ball BGAIndustrial -40°C to 85°C
E5-153IT1-128G128GB3D TLC (128-Layer)153-ball BGAIndustrial -40°C to 85°C
