Centon, 153-ball BGA (Industrial), 3D TLC (112-Layer), 128GB

Product Details
JEDEC eMMC 5.1 compliant. Single-package managed NAND: MLC die + integrated controller behind a
standard eMMC interface. On-controller flash management includes ECC, wear-leveling, IOPS optimization,
and read sensing, isolating the host from NAND-level complexity and reliability handling. Suitable as a
universal embedded storage component for systems requiring standardized, host-transparent non-volatile
storage.

Item No. E5-153IT2-128G
Interface eMMC 5.1 HS400
Form Factor 153-ball BGA
Operating Temperature Industrial: -40 to +85C
Size 128GB
Sequential Write (MB/s) 130
Sequential Read (MB/s) 310
Voltage 3.3V
I/O Voltage (VCCQ) 3.3V/1.8V
W/E Endurance ≥ 3K
Package Size 11.5 × 13.0 × 1.0 mm
Data Retention 1-Year @ life-end | 10-Years @ initial

Similar parts

View all →
Part numberPackageTemperatureCapacityNAND
E5-100IP-4G100-ball BGAIndustrial -40°C to 85°C4GBpSLC
E5-100IM-8G100-ball BGAIndustrial -40°C to 85°C8GBMLC
E5-100IM-16G100-ball BGAIndustrial -40°C to 85°C16GBMLC
E5-153IP-4G153-ball BGAIndustrial -40°C to 85°C4GBpSLC
E5-153IM-8G153-ball BGAIndustrial -40°C to 85°C8GBMLC
E5-153IM-16G153-ball BGAIndustrial -40°C to 85°C16GB3D TLC (64-Layer)
E5-153IT1-32G153-ball BGAIndustrial -40°C to 85°C32GB3D TLC (64-Layer)
E5-153IT2-64G153-ball BGAIndustrial -40°C to 85°C64GB3D TLC (112-Layer)
E5-153IT2-256G153-ball BGAIndustrial -40°C to 85°C256GB3D TLC (112-Layer)
E5-153IT1-64G153-ball BGAIndustrial -40°C to 85°C64GB3D TLC (128-Layer)
E5-153IT1-128G153-ball BGAIndustrial -40°C to 85°C128GB3D TLC (128-Layer)
