Centon, 153-ball BGA (Automotive Grade 2), MLC, 16GB
Centon, 153-ball BGA (Automotive Grade 2), MLC, 16GB
1/2 Images

Centon, 153-ball BGA (Automotive Grade 2), MLC, 16GB

Product Details
JEDEC eMMC 5.1 compliant. Single-package managed NAND: MLC die + integrated controller behind a
standard eMMC interface. On-controller flash management includes ECC, wear-leveling, IOPS optimization,
and read sensing, isolating the host from NAND-level complexity and reliability handling. Suitable as a
universal embedded storage component for systems requiring standardized, host-transparent non-volatile
storage.

Item No. E5-153AM-16G
Interface eMMC 5.1 HS400
Form Factor 153-ball BGA
Operating Temperature Automotive Grade 2: -40 to +105C
Size 16GB
Sequential Write (MB/s) 125
Sequential Read (MB/s) 320
Voltage 3.3V
I/O Voltage (VCCQ) 3.3V/1.8V
W/E Endurance ≥ 3K
Package Size 11.5 × 13.0 × 1.0 mm
Data Retention 1-Year @ life-end | 10-Years @ initial

Similar parts

View all →
Part numberPackageTemperatureCapacityNAND
E5-100AP-4G100-ball BGAAutomotive -40°C to 105°C4GBpSLC
E5-100AM-8G100-ball BGAAutomotive -40°C to 105°C8GBMLC
E5-100AM-16G100-ball BGAAutomotive -40°C to 105°C16GBMLC
E5-153AP-4G153-ball BGAAutomotive -40°C to 105°C4GBpSLC
E5-153AM-8G153-ball BGAAutomotive -40°C to 105°C8GBMLC
E5-153AT1-32G153-ball BGAAutomotive -40°C to 105°C32GB3D TLC (64-Layer)
E5-153AT1-64G153-ball BGAAutomotive -40°C to 105°C64GB3D TLC (64-Layer)
E5-153AT1-128G153-ball BGAAutomotive -40°C to 105°C128GB3D TLC (64-Layer)
E5-153AT2-64G153-ball BGAAutomotive -40°C to 105°C64GB3D TLC (112-Layer)
E5-153AT2-128G153-ball BGAAutomotive -40°C to 105°C128GB3D TLC (112-Layer)
E5-153AT2-256G153-ball BGAAutomotive -40°C to 105°C256GB3D TLC (112-Layer)
