Centon, 153-ball BGA (Extended), 3D TLC (112-Layer), 16GB

Product Details
eMMC 5.1 puts NAND flash and its controller in one soldered BGA package, with ECC, wear leveling and bad-block management built in, so your design boots and runs from a single chip that cannot shake loose. Choose the temperature grade and NAND type (pSLC, MLC or 3D TLC) that fit your endurance and cost targets. Centon builds it to a controlled bill of materials with full lot traceability and keeps it in supply for long-running embedded programs.

Item No. E5-153CT2-16G
Interface eMMC 5.1 HS400
Form Factor 153-ball BGA
Operating Temperature Extended: -25 to +85C
Size 16GB
Sequential Write (MB/s) 109
Voltage 3.3V
I/O Voltage (VCCQ) 3.3V/1.8V
W/E Endurance ≥ 3K
Package Size 11.5 × 13.0 × 1.0 mm
Data Retention 1-Year @ life-end | 10-Years @ initial
Lifecycle StatusProduction
RoHSCompliant
REACHCompliant
MOQLow MOQ
Lead TimeQuoted per order
Optima: BOM control

Critical parts fixed. NAND may move to qualified equivalents under the same part number.

Optima+: 100% BOM control

Every part locked. Any change gets a new part number.

Same specifications. Our sales team will help you choose.

Similar parts

View all →
Part numberCapacityNANDPackageTemperature
E5-153CM-4G4GBMLC153-ball BGAExtended -25°C to 85°C
E5-153CM-8G8GBMLC153-ball BGAExtended -25°C to 85°C
E5-153CT1-8G8GB3D TLC (64-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT1-16G16GB3D TLC (64-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT1-32G32GB3D TLC (64-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-16GThis part16GB3D TLC (112-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-32G32GB3D TLC (112-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-64G64GB3D TLC (176-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-128G128GB3D TLC (176-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-256G256GB3D TLC (176-Layer)153-ball BGAExtended -25°C to 85°C
E5-153CT2-512G512GB3D TLC (176-Layer)153-ball BGAExtended -25°C to 85°C
