Centon, 153-ball BGA (Extended), 3D TLC (176-Layer), 256GB
Centon, 153-ball BGA (Extended), 3D TLC (176-Layer), 256GB
1/2 Images

Centon, 153-ball BGA (Extended), 3D TLC (176-Layer), 256GB

Product Details
JEDEC eMMC 5.1 compliant. Single-package managed NAND: MLC die + integrated controller behind a
standard eMMC interface. On-controller flash management includes ECC, wear-leveling, IOPS optimization,
and read sensing, isolating the host from NAND-level complexity and reliability handling. Suitable as a
universal embedded storage component for systems requiring standardized, host-transparent non-volatile
storage.

Item No. E5-153CT2-256G
Interface eMMC 5.1 HS400
Form Factor 153-ball BGA
Operating Temperature Extended: -25 to +85C
Size 256GB
Sequential Write (MB/s) 280
Sequential Read (MB/s) 320
Voltage 3.3V
I/O Voltage (VCCQ) 1.8V/3.3V
W/E Endurance ≥ 3K
Package Size 11.5 × 13.0 × 1.0 mm
Data Retention 1-Year @ life-end | 10-Years @ initial

Similar parts

View all →
Part numberPackageTemperatureCapacityNAND
E5-153CM-4G153-ball BGACommercial -25°C to 85°C4GBMLC
E5-153CM-8G153-ball BGACommercial -25°C to 85°C8GBMLC
E5-153CT1-8G153-ball BGACommercial -25°C to 85°C8GB3D TLC (64-Layer)
E5-153CT1-16G153-ball BGACommercial -25°C to 85°C16GB3D TLC (64-Layer)
E5-153CT1-32G153-ball BGACommercial -25°C to 85°C32GB3D TLC (64-Layer)
E5-153CT2-16G153-ball BGACommercial -25°C to 85°C16GB3D TLC (112-Layer)
E5-153CT2-32G153-ball BGACommercial -25°C to 85°C32GB3D TLC (112-Layer)
E5-153CT2-64G153-ball BGACommercial -25°C to 85°C64GB3D TLC (176-Layer)
E5-153CT2-128G153-ball BGACommercial -25°C to 85°C128GB3D TLC (176-Layer)
E5-153CT2-512G153-ball BGACommercial -25°C to 85°C512GB3D TLC (176-Layer)
